STG50700 Starter 0R9703 144-9966 for Caterpillar Excavators – Mini 302.5 1999-On
Key Specifications:
Item Condition: Aftermarket Part
Unit Type: Starter
Part Type: Unit
Voltage: 12V
Rotation: Clockwise (CW)
Teeth: 11T
Power: 2.0KW
Starter Type: OSGR (Offset Starter Gear Reduction)
Compatibility:
This starter motor is compatible with the following brands and part numbers:
Caterpillar Excavators:
Model: Mini 302.5 (1999 and later)
Part Numbers: 0R9703, 144-9966
Arrowhead:
Part Numbers: SND0760, 410-52382
Denso:
Part Number: 228000-7530
Features:
2.0KW Power Output: Ensures reliable starting performance for mini excavators.
12V Operation: Suitable for standard automotive and industrial applications.
Clockwise Rotation: Designed for engines requiring CW rotation.
11-Tooth Pinion: Ensures proper engagement with the flywheel.
Offset Starter Gear Reduction (OSGR): Provides high torque output with compact design.
Durable Construction: Built to withstand harsh operating conditions.
Applications:
This starter motor is ideal for use in:
Caterpillar Mini 302.5 Excavators (1999 and later).
Other equipment or vehicles compatible with the listed part numbers.
STG50700 Starter 0R9703 144-9966 for Caterpillar Excavators – Mini 302.5 1999-On
| MAKE | TYPE | MODEL | YEAR | ENGINE |
| CATERPILLAR | Excavators - Mini | 302.5 | 1999 - On | Cat. 3013 (22.9HP Dsl) |
| CATERPILLAR | Excavators - Mini | 303.5 | 1999 - On | Cat. 3013 (26.1HP Dsl) |
